| Sectional Dimension (mm) |
Weight |
Sectional
Area cm2 |
| H x B |
t1 |
t2 |
r1 |
r2 |
kg/m |
kg/6m |
| 50 x 25 |
5.0 |
6.0 |
6 |
3.0 |
3.86 |
23.16 |
4.92 |
| 75 x 40 |
5.0 |
7.0 |
8 |
4.0 |
6.92 |
41.52 |
8.82 |
| 100 x 50 |
5.0 |
7.5 |
8 |
4.0 |
9.36 |
56.16 |
11.92 |
| 125 x 65 |
6.0 |
8.0 |
8 |
4.0 |
13.40 |
80.40 |
17.11 |
| 150 x 75 |
6.5 |
10.0 |
10 |
5.0 |
18.60 |
111.60 |
23.71 |
| |
9.0 |
12.5 |
15 |
7.5 |
24.00 |
144.00 |
30.59 |
| 180 x 75 |
7.0 |
10.5 |
11 |
5.5 |
21.40 |
128.40 |
27.20 |
| 200 x 80 |
7.5 |
11.0 |
12 |
6.0 |
24.60 |
147.60 |
31.33 |
| 200 x 90 |
8.0 |
13.5 |
14 |
7.0 |
30.30 |
181.80 |
38.65 |
| 250 x 90 |
9.0 |
13.0 |
14 |
7.0 |
34.60 |
207.60 |
44.07 |
| |
11.0 |
14.5 |
17 |
8.5 |
40.20 |
241.20 |
51.17 |
| 300 x 90 |
9.0 |
13.0 |
14 |
7.0 |
38.10 |
228.60 |
48.57 |
| |
10.0 |
15.5 |
19 |
9.5 |
43.80 |
262.80 |
55.74 |
| |
12.0 |
16.0 |
19 |
9.5 |
48.60 |
291.60 |
61.90 |
| 380 x 100 |
10.5 |
16.0 |
18 |
9.0 |
54.50 |
327.00 |
69.39 |
| |
13.0 |
16.5 |
18 |
9.0 |
67.00 |
372.00 |
78.96 |
| |
13.0 |
20.0 |
24 |
12.0 |
67.30 |
403.80 |
85.71 |
|
|
|
|
|
|
|
|
| |
